The TWSA amplifier is designed for wideband applications, where satellite frequencies from 290 MHz to 2340 MHz are used. The amplifier has two inputs, one for the vertical and one for the horizontal feed. The low band and high bands are combined on one feed. This amplifier is compatible with wideband LNBs.
CHARACTERISTICS
Type: Amplifier - wideband
Max. output level SAT @ -35 dB IMD3: 117 dBµV
FREQUENCY
Frequency range SAT: 290...2340 MHz
GAIN
Gain: 30 dB
Gain Adjustment: 15
Slope: 15 dB
ELECTRICAL
Impedance: 75 Ω
OPERATIONAL
Power Consumption (typ.): 3 W
CONNECTORS
Connector IN: F-female
Connector OUT: F-female
Number of inputs: 2
Number of outputs: 2
MECHANICAL
Dimensions product (H x D x W): 177x133x51 mm
