The TWS2 splitter is designed to be used with Wideband systems with Satellite IF frequencies from 290 MHz to 2340 MHz, and Terrestrial frequencies between 5 MHz and 862 MHz.
CHARACTERISTICS
Type: Splitter
FREQUENCY
Frequency range SAT: 290...2340 MHz
Frequency range TER: 5...862 MHz
LOSS
Insertion loss - SAT: 4.5 dB
Insertion loss - TER: 3.5...4.0 dB
ELECTRICAL
Impedance: 75 Ω
CONNECTORS
Connector IN: F-female
Connector OUT: F-female
Number of inputs: 3
Number of outputs: 6
MECHANICAL
Dimensions product (H x D x W): 130x130x50 mm
