The TRIAX TWCD Optical Dual Wideband and TERR Receiver is developed for the transmission of broadband signals in medium and large Fiber Optic systems.
It converts 1310 + 1330 + 1350 + 1370 + 1550 nm to 2 x V/H and TERR signals.
- Up to 32 passive splits
- Optical Input Level: -4 to -12 dBm
- Frequency Range: 40 2400 MHz
- High reception quality even with high split ratios
- Powering via V/H output (12-20V)
- AGC to boost signal level
- Optical wavelengths: 1310-1330-1350-1370-1550nm
- Compatible with Triax TdSCR wideband Multiswitches
Optical inputs: 1
RF outputs: Dual Wideband + TERR
Optical wavelengths (nm): 1310 - 1330 - 1350 - 1370 - 1550
Frequency range TERR (MHz): 40 1218
Frequency range SAT (MHz): 950 2400
Optical input level (dBm): -4 to -12 dBm
Signal indicator: Green LED per wavelength
Output level dSCR (AGC) (dBµV): 80
Return loss (dB): -8 (Typ -12)
Input connector type: SC / APC
Output connector type: 75 ohm F type (female)*
Power consumption (W): 5
Power supply via DC IN (VDC): 12 20 (via V or H port (F-type))
Power indicator: Green LED
Operating temperature range (°C): -10 to +55
Dimensions (mm): 166 x 136 x 50
Weight (kg): 0.375
* Unused ports need to be terminated with 75 Ohm DC-blocked terminator
