TRIAX SCS-3 3 Way F Splitter (5-2400MHz)

SKU: 349823

  Product Documents

TRIAX SCS-3 3 Way F Splitter (5-2400MHz)


SCS 3 - 3 way splitter
Main features:

  • RF shielded zinc die-cast housing with nickel plating
  • All ports F type 75 ohm
  • All output ports DC pass
  • Fixing screws supplied
  • Low insertion loss
  • High isolation for UHF/IF distribution
  • Earth terminal built into housing

Screening
40-470 MHz > 75dB
470-1000 MHz > 65dB
1000-2400 MHz > 55dB
Insertion Loss (dB)
5-40 MHz: 7
470-860 MHz: 7.5
1000-2050 MHz: 10.0
2050-2400 MHz: 11.0
Mutual Isolation (dB)
5-40 MHz: 22
470-860 MHz: 22
1000-2050 MHz: 20
2050-2400 MHz: 20
Return Loss (dB)
5-40 MHz: 10
470-860 MHz: 12
1000-2050 MHz: 12
2050-2400 MHz: 12
