SCS 2 - 2 way splitter
Main features:
- RF shielded zinc die-cast housing with nickel plating
- All ports F type 75 ohm
- All output ports DC pass
- Fixing screws supplied
- Low insertion loss
- High isolation for UHF/IF distribution
- Earth terminal built into housing
Screening
40-470 MHz > 75dB
470-1000 MHz > 65dB
1000-2400 MHz > 55dB
Insertion Loss (dB)
5-40 MHz: 4
470-860 MHz: 5
1000-2050 MHz: 5.8
2050-2400 MHz: 6.5
Mutual Isolation (dB)
5-40 MHz: 14
470-860 MHz: 22
1000-2050 MHz: 22
2050-2400 MHz: 22
Return Loss (dB)
5-40 MHz: 12
470-860 MHz: 15
1000-2050 MHz: 14
2050-2400 MHz: 12
