T.0X (WDM) optical multiplexer
1610 nm - 1550 nm
Passive device that multiplexes/demultiplexes two optical inputs: 1610 nm (GPON), and 1550 nm (Downlink). For application in RFoG systems.
The T.0X format frame allows rack installation for optical fibre headends.
MAIN FEATURES
- Low insertion loss
- SC/APC connectors
OPTICAL CHANNEL PERFORMANCE
Working wavelength (nm): 1600…1620
Insertion losses (λ) 1310/1490 nm (dB): ---
Insertion losses (λ) 1610 nm (dB): 0,6
Insertion losses (λ) 1550 nm (dB): > 13
Potencia óptica máx. (dBm): +24
Working wavelength (nm): 1540…1565
Insertion losses (λ) 1310/1490 nm (dB): ---
Insertion losses (λ) 1610 nm (dB): >30
Insertion losses (λ) 1550 nm (dB): 0,4
Potencia óptica máx. (dBm): +24
GENERAL OPTICAL PERFORMANCE
Return losses (dB): > 50
Directivity (dB): > 50
PDL (dB): < 0,1
PMd (ps): < 0,1
Optical conNectors (Type): SC / APC
GENERAL PERFORMANCE
Operating Temp: -5 ... +45 ºC
Protection index (IP): 20
