COMBINED OPTICAL/RJ45/ VFL METER.
Mainly used for continuous optical signal power measurement, optical fibre loss rate testing, optical fibre line on-off testing and RJ45 cable sequence testing. Widely used in optical cable construction and maintenance, optical fibre communication, optical cable sensing, optical CATV and other fields.
This handheld meter has a durable case, compact shape, automatic shutdown function, three red light modes, backlight display, wavelength memory function, optical fibre identification, support user Calibration Configuration, wide test range and supports a work light.
MAIN FEATURES:
- -50+26dbm, VFL 15mw
- 4 in 1 mini meter
- OPM (Optical Power Meter)
- RJ45 Cable Tester
- VFL (Visual Fault Locater)
- LED light (white)
- 10 freqs of wavelengths
- Covers 10G EPON/X GPON downlinks 1490/1577nm
SPECIFICATIONS:
Optical Power Meter:
Wavelength range: 800~1700nm
Connector: Universal joint
Detector type: InGaAs
Power test range: -70~+6dBm | -50~+26dBm
Uncertainty: +/-
Standard wavelength: 850/980/1270/1300/1310/1490/1550/1577/1625/1650nm
Display resolution: Linear display: 0.1%, logarithmic display: 0.01dBm
Recognisable frequency; 270Hz, 330Hz, 1kHz, 2kHz
VFL (optional):
Wavelength: 650nm+/-30nm
Output power: 2mw/15mw/30mw/50mw
Mode: CW/1Hz/2Hz
Connector: Universal joint
RJ45 cable sequence (standard), cable tracking (optional):
Test distance: 300m
Power supply: 2 x AAA batteries /Lithium battery, 3.7V/700mAh (optional)
Port: Type C
Battery duration: >120h (OPM)
Automatic shutdown time: 10 min
Working temperature: -10degreeC~+50degreeC
Storage temperature: -40degreeC~+70degreeC
Relative humidity: 0~95% No condensation
Dimension: 110mm x 68mm x 27mm
Weight: 130g
