100m Pre-Terminated LC/LC 4 Core Fibre, a UK-produced pre-term assembly, meticulously fabricated and inspected for Multimode OM4 in 4 cores. This product is designed with the installer in mind, featuring LC connectors with machine-polished ceramic ferrules for low loss, ensuring efficient installation in an Optical Distribution Frame (ODF), patch panel, or enclosure.
Key Selling Features:
• Manufactured in the UK and factory tested.
• High-quality LC connectors with low-loss, machine-polished ceramic ferrules.
• Comes with crush-resistant tubing for secure transport, assuring fast and convenient installation.
• Furnished with removable protective tubing and an optional pulling eye.
• Appropriate for usage in internal horizontal and backbone cabling, ensuring flexible application.
Technical Specifications:
• Length: 100m
• Construction: Tight Buffered 900um, Multimode OM4, 4 cores.
• 4 Core Cable Diameter: 5.9mm.
• Maximum Crush Resistance: 1000N.
• Long-Term Load: 400N; Short-Term Load: 1000N.
• Features Glass Yarn Flexible Strength Members.
• Cable Sheath/CPR Compliance with Low Smoke Zero Halogen (HFFR-LS) Black.
• Minimum Bend: Static - 10 x Cable Diameter, Dynamic - 15 x Cable Diameter.
• Operational Temperature Range: -20°C to +60°C.
• Attenuation OM4 50/125: @850nm > 2.8 db/km, @1300nm > 0.8 db/km
• Compliances: TIA-598-C, IEC 60794-2-20, IEC 60794-1-21, IEC 60794-1-22, IEC 60332-1-2.
The 100m Pre-Terminated LC/LC 4 Core Fibre ensures swift, efficient future-proof installations with advanced technical features. Made in the UK and compliant with international standards, it's a reliable choice for your next cabling project.
