This range of Whyte Fibre Optic Distribution Boxes provide a robust and flexible solution for indoor and outdoor fibre termination. They come with in-built cassette splitter positions, splice trays with a colour-coded labelling system and ample cable access ports. Designed to be used with either pre-terminated or multicore fibre cables they are supplied with an array of installation accessories and consumables for the ultimate convenience of the end-user.
The 16, 32 and 64-Way Fibre Distribution Boxes also offer the possibility of stacking multiple boxes thanks to top and bottom cable access ports.
- Built to withstand harsh environmental conditions
- Colour coded labelling system for fibre identification
- Complete with installation accessories, ready to fit
- Suitable for multi-core and pre-terminated fibre cables
- Colour coded labelling system TIA-598
- Splice trays with colour coded labelling system
- Cassette splitter mounting points
- Splice tray with fibre raceway
Specifications:
Splice Capacity: 72
Cassette Size Options: Up to 2x 32 Way Cassette (Horizontal fixing)
Adaptor Bracket Included: 64 Way
Mounting: Wall / Pole*
Cable Mounting: Vertical
Cable Access Ports Top: 6
Cable Access Ports Bottom: 6
Fibre Identification Label: TIA-598 Standard
Splice Protectors: 64 x 60mm
Rawl plugs: 4
Mounting screws: 4
Small cable ties: 16
Key: 1
Cable Sleeve mm: 5 x 600 (6pcs)
Earth Blocks: Fitted
M32 Compression Gland: 2
M20 Compression Gland: 2
M15 Compression Gland: 2
Jubilee Clips: 2
Colour: Signal White RAL9003
Main Material: UV Resistant ABS Plastic
IP Rating: IP65
Compliance: RoHS, Reach / SVHC
Operating Temperature: -40 ~ +80ºC
Storage Temperature: -40 ~ +80ºC
*Pole mounting kit available separately.
