This ultra-reliable UPS features a high power density, true online double-conversion technology, connectivity that is future-proof, and seamless cloud integration. Symphony is an excellent option for IT and facility managers who are concerned about rising energy costs and searching for the power protection solutions of the next generation.
The Symphony series has a unity power factor (kVA = kW) and delivers more power than other comparable UPS systems while reducing energy and cooling costs. Using the user-friendly LCD panel or Uniti Power software, Symphony can monitor and measure energy consumption. Due to the optional network card and Uniti Power software suite, Symphony is compatible with the leading virtualisation environments and cloud orchestration platforms.
- High Efficiency = Energy Saving
- Unity power factor
- 6-year warranty
- Parallel up to 3 units
- Extended run times available
Technical Specification:
Power rating: 6000VA/6000W
Efficiency - Double conversion mode: 95%
Efficiency - Eco mode: 98%
Input voltage range: 160-275V 100% load, 110-160V derating to 50% load linearly
Input rated frequency: 50Hz/60Hz
Input frequency range: 40Hz-70Hz (45Hz-55Hz 54Hz-66Hz @ load>60%)
Input PF: >0.995
Input THDI: <3% linear load, <5% non linear load
Input connection: L/N/PE hardware terminnal connection
Output rated voltage: 220/230/240V
Output rated frequency: 50Hz/60Hz
Output maximum PF: 1
Output voltage accuracy: ±1%
Output THDv: <1% linear load, <5% non linear load
Output transfer time: 0ms (10ms @ ECO->Inverter)
Output crest ratio: Max 3:1
Output overload (line mode): "100% 150% for 500ms"
Output wiring/socket: L/N/PE hardware terminal connection
Output load segment control: Optional
Battery voltage: 240VDC
Extended battery option: EBM2409RT3U
Max external battery modules: 6
Charging current: 4A (0-12A adjustable)
CVCF working mode: Yes (derating to 60% load)
Parallel working mode: Optional (up to 3)
Display: Dot matrix LCD, rotatable manually
Language: 10 Languages
USB: USB 2.0 with HID
RS232: Yes (DB9)
Dry in/out: 1 programmble dry in; 1 programmble dry out
EPO: Yes
Intelligent slot: Yes (for long card)
Network card: Optional, NMC long card
Dry contactor card: Optional, AS400 Long Card
Ethernet port for IOT: RJ45
Monitor software: Winpower
Dimension (WxDxH) (mm): 438x573x86.2 (power module, 2U)
Net weight (kg): 13.6
IP protection level: IP20
Operating temperature: 0-50⁰C (power derating to 50% @40-50⁰C)
Relative Humidity: 0-95%
Operating Altitude: 0-3000m (the load derating 1 % every up 100m @1000-3000m)
Acoustic Noise: <50dB @ typical load with battery fully charge
Certification: CE,IEC/EN 62040
EMI conduction/radiation: C3
EBM cable: Yes (in EBM)
USB cable: Yes
RS232 cable: Optional
Rail kit: Optional
Tower feet: Yes
Rack ear: Yes
Manual: Yes
Warranty: 6-year parts
