This ultra-reliable UPS features a high power density, true online double-conversion technology, connectivity that is future-proof, and seamless cloud integration. Symphony is an excellent option for IT and facility managers who are concerned about rising energy costs and searching for the power protection solutions of the next generation.
The Symphony series has a unity power factor (kVA = kW) and delivers more power than other comparable UPS systems while reducing energy and cooling costs. Using the user-friendly LCD panel or Uniti Power software, Symphony can monitor and measure energy consumption down to the outlet group level. Due to the optional network card and Uniti Power software suite, Symphony is compatible with the leading virtualisation environments and cloud orchestration platforms.
- High Efficiency = Energy Saving
- Unity power factor
- Hot swappable batteries
- 6-year warranty
- Extended run times available
Technical Specification:
Power rating: 1500VA/1500W
Efficiency - Double conversion mode: 89%
Efficiency - Eco mode: 97%
Input voltage range: 160-300V 100% load, 110-160V derating to 50% load linearly
Input rated frequency: 50Hz/60Hz
Input frequency range: 40Hz-70Hz (45Hz-55Hz 54Hz-66Hz @ load>60%)
Input PF: >0.99
Input THDI: <5%
Input connection: IEC C14
Output rated voltage: 200/208/220/230/240VAC (derating 10% at 208V, derating 20% at 200V)
Output rated frequency: 50Hz/60Hz
Output maximum PF: 1
Output voltage accuracy: ±1%
Output THDv: <1% linear load, <5% non linear load
Output transfer time: 0ms (4ms @ line <-> bypass;10ms @ ECO <->Inverter)
Output crest ratio: Max 3:1
Output overload (line mode): "100% 150% for 500ms"
Output wiring/socket: 1 main outlet group (with 4 x IEC C13) + 1 programmable outlet group (with 4 x IEC C13)
Output load segment control: Yes
Battery voltage: 36VDC
Battery capacity (Ah): 3 x 12V/9Ah
Replacement battery kit: URBK1
Extended battery option: EBM369RT2U
Max external battery modules: 4
Charging current: 1.5A
Recharging time: 3h to 90%
CVCF working mode: Yes (derating to 60% load)
Display: Dot matrix LCD, rotatable manually (optional segment LCD)
Language: 10 Languages
USB: USB 2.0 with HID
RS232: Yes (DB9)
Dry in/out: 1 programble dry in; 1 programble dry out
EPO: Yes
Inteligent slot: Yes (for long card)
Network card: Optional, NMC long card
Dry contactor card: Optional, AS400 Long Card
Ethernet port for IOT: RJ45
Monitor software: Winpower
Dimension (WxDxH) (mm): 438x445x86.5 (2U)
Weight (kg): 15.8
IP protection level: IP20
Operating temperature: 0-40⁰C
Relative Humidity: 0-95%
Operating Altitude: 0-3000m (the load derating 1 % every up 100m @1000-3000m
Acoustic Noise: <45dB @ typical load with battery fully charge
Certification: CE,IEC/EN 62040
EMI conduction/radiation: C2
Input power cable: Yes
Output power cable: Yes, 1 x 10A
EBM cable: Yes (in EBM)
USB cable: Yes
RS232 cable: Optional
Rail kit: Optional
Tower feet: Yes
Rack ear: Yes
Manual: Yes
Warranty: 6-year parts/2-year batteries as standard
Runtime:
Full Load: 3 mins
75% Load: 5 mins
50% Load: 9 mins
25% Load: 20 mins
