The Uniti Power Echo 3000VA / 2700W Online Rack UPS delivers professional-grade power protection in a compact, short-depth 2U rack design suited to modern IT environments. Utilising true online double-conversion technology, the Echo 3000VA continuously regenerates output power, isolating connected equipment from voltage fluctuations, frequency instability, noise and other mains disturbances.
Unlike UPS models with internal batteries, the Echo 3000VA is built with an external battery architecture, allowing the unit to maintain a shallow rack footprint while providing scalable runtime through dedicated external battery modules. This makes it ideal for environments where space is at a premium — such as shallow comms racks, wall cabinets and distributed IT closets — without compromising on UPS performance.
The Echo 3000VA maintains a high 0.9 output power factor, delivering more usable power for servers, network switches, firewalls and security systems. Its wide input voltage tolerance (90–275 VAC) reduces unnecessary battery use, helping prolong battery life and enhancing system stability.
Key operational information is clearly displayed via the intuitive LCD interface, which shows load level, battery status, input and output values, operating mode and alarms. For enhanced system oversight, the Echo 3000VA supports optional network monitoring via the UPNETG2S card, compatible with Uniti Power’s WinPower G2 and SPS G2 software for remote monitoring, alerts and graceful shutdown.
Quiet operation and robust protection features make the Echo 3000VA a practical choice for critical network infrastructure, data communications and edge compute setups. Backed by a 3-year warranty, this UPS delivers reliable, professional online power protection with external battery scalability.
- True Online Double-Conversion Protection
- Compact 2U Short-Depth Rack Design
- External Battery Support for Scalable Runtime
- High 0.9 Output Power Factor
- Optional UPNETG2S Network Monitoring
Technical Specification:
Power rating: 3000VA/2700W
Input Nominal Voltage: HV: 208/220/230/240VAC
Input Frequency: 50/60Hz
Input Voltage Range: HV: 90~275VAC±5VAC
Input Frequency Range: (40~70)±0.5Hz
Input Power Factor: >0.99
Bypass Voltage Range: HV: 187~265V/ (120~275VAC Max)
Input Connection: IEC C20
Output Power Factor: 0.9
Output Nominal Voltage: 208V/220/230/240VAC, 230V Default
Output Voltage Regulation: +/-1%
Output Frequency Range: 50/60Hz +/-0.05%
Over Load: 100%~105% continuous. 60Sec.@105%~130% Rated Load
Voltage Distortion (THDv): <2% @ linear load
Output Waveform: Pure Sine Wave
Efficiency, Line Mode: 91%
Efficiency, Battery Mode: 87%
Battery Nominal Voltage: 72V
Battery Type: 12V/9Ah
Number of Internal Batteries: 0
Rated Battery Voltage: -
Charging Current: 4A
Recharge Time (to 90%): N/A
Transfer Time, Battery Mode <-> Inverter Mode: 0ms
Transfer Time, Inverter Mode <-> Bypass Mode: <4ms
Transfer Time, ECO Mode <-> Battery Mode: <10ms
Display: Programmable LCD
Audible Alarm: Yes
Protection Function: AC input or output above or below the range of voltage, overload, over temperature and short circuit protection.
Protection: Discharge, overcharge and overload protection.
Product Dimensions WxHxD: 439.8 x 88 x 428 mm
Product Weight: 9.3kg
Operating Temperature: Operating Temperature
Regulation: CE
Noise Level: <50dB (ISO 7779 @ front 1m distance, without buzzer)
IP Rating: IP20
RS232/USB: Yes
External Slot: Yes, for optional UPNETG2S Card
Emergency Power Off: Yes
Standard Warranty: 3-year parts/1-year batteries
