The Uniti Power Echo 2000VA / 1800W Online Rack UPS is designed to deliver dependable, professional-grade power protection for modern IT and networking environments. Using true online double-conversion technology, Echo completely isolates connected equipment from mains disturbances, ensuring a continuous supply of clean, stable power at all times.
Unlike line-interactive UPS systems, Echo regenerates the output waveform continuously, protecting sensitive equipment from voltage fluctuations, frequency instability, surges and power interruptions. With a 0ms transfer time, connected systems remain powered without interruption during mains failure, making Echo ideal for critical applications such as network switches, firewalls, security systems and small servers.
The compact 2U short-depth rack-mount design makes the Echo 2000VA particularly well suited to shallow comms racks, wall cabinets and space-restricted installations. Despite its small footprint, the unit delivers a high 0.9 output power factor, providing more usable power for modern IT loads.
A wide input voltage range of 90–275 VAC allows the UPS to remain in online mode for longer during unstable mains conditions, reducing unnecessary battery usage and helping to extend battery life. An intuitive programmable LCD display provides clear, real-time information on load, battery status, input and output values, alarms and operating mode.
For intelligent monitoring and control, the Echo 2000VA includes an intelligent expansion slot compatible with the UPNETG2S network management card, enabling secure remote monitoring via SNMP, Modbus TCP, MQTT or REST API. The UPS also supports WinPower G2 and SPS G2 software for automated shutdown and advanced power management across connected systems.
Quiet operation, robust internal protection features and support for EPO and ROO connections make the Echo range a practical and reliable choice for distributed IT environments where uptime, efficiency and space efficiency are essential.
Backed by a 3-year warranty, the Uniti Power Echo 2000VA Online UPS offers compact, professional online protection for everyday critical power applications.
- True Online Double-Conversion Protection
- Compact 2U Short-Depth Rack Design
- High 0.9 Output Power Factor
- Wide Input Voltage Range
- Advanced Monitoring & Management
Technical Specifications:
Power rating: 2000VA/1800W
Input Nominal Voltage: HV: 208/220/230/240VAC
Input Frequency: 50/60Hz
Input Voltage Range: HV: 90~275VAC±5VAC
Input Frequency Range: (40~70)±0.5Hz
Input Power Factor: >0.99
Bypass Voltage Range: HV: 187~265V/ (120~275VAC Max)
Input Connection: IEC-C14
Output Power Factor: 0.9
Output Nominal Voltage: 208V/220/230/240VAC, 230V Default
Output Voltage Regulation: +/-1%
Output Frequency Range: 50/60Hz +/-0.05%
Over Load: 100%~105% continuous. 60Sec.@105%~130% Rated Load
Voltage Distortion (THDv): <2% @ linear load
Output Waveform: Pure Sine Wave
Efficiency, Line Mode: 90%
Efficiency, Battery Mode: 86%
Battery Nominal Voltage: 48V
Battery Type: 12V/9Ah
Number of Internal Batteries: 2
Rated Battery Voltage: 48V DC
Charging Current: 1A
Recharge Time (to 90%): 5 hours
Transfer Time, Battery Mode <-> Inverter Mode: 0ms
Transfer Time, Inverter Mode <-> Bypass Mode: <4ms
Transfer Time, ECO Mode <-> Battery Mode: <10ms
Display: Programmable LCD
Audible Alarm: Yes
Protection Function: AC input or output above or below the range of voltage, overload, over temperature and short circuit protection.
Protection: Discharge, overcharge and overload protection
Product Dimensions WxHxD: 439.8 x 88 x 428 mm
Product Weight: 18kg
Operating Temperature: Operating Temperature
Regulation: CE
Noise Level: <50dB (ISO 7779 @ front 1m distance, without buzzer)
IP Rating: IP20
RS232/USB: Yes
External Slot: Yes, for optional UPNETG2S Card
Emergency Power Off: Yes
Standard Warranty: 3-year parts/1-year batteries
