Spare/replacement Power supply for use with the Ubiquiti AF24, AF24HD, AF5 and AF5U AirFiber products.
Specifications
Dimensions: 100.95 x 60 x 33 mm (3.97 x 2.36 x1.30 in)
Weight: 192 g (6.77 oz)
Output Volage: 50VDC @ 1.2A
LAN Activity Indicator: No
Gigabit LAN Port: Yes
Remote Reset Capability: No
Reset Button: No
Input Voltage: 90-260VAC @ 47-63 Hz
Input Current: 0.6A @ 120VAC, 0.4A @ 240VAC, 1.3A @ 120VAC, 0.75A @ 240VAC
Inrush Current: <100A Peak @120VAC, <200A Peak @ 230VAC
Efficiency: 85+%
Output Ripple: 1% Max.
Switching Frequency: 65 kHz
Line Regulation: ± 1%
Load Regulation: ± 3%
4-Pair Powering: Pins 1, 2, 4, 5 (+) and Pins 7, 8, 3, 6 (-)
Operating Temperature: 0 to 40° C (32 to 104° F)
Storage Temperature: -30 to 70°C (-22 to 158° F)
Operating Humidity: 35 to 95% Non-Condensing
AC Connector: IEC-320 C6
Data IN / POE: RJ45 Shielded Socket
Surge Protection:Difference and Common Mode
Clamping Protection: 11V Data, 60V Power
Max. Surge Discharge: 1500A (8/20µS) Power
Peak Pulse Current: 36A (10/1000µS) Data
Shunt Capacitance: <5 pf data
Response Time: <1 nS
Compliance: IEC 60950-1:2005+A1, UL60950-1, EN55022:2010, EN55024:2010, FCC Class B
