Recomended split ratio 1:32
The TDC-5 is an Optical Fibre Receiver, from the TRIAX Optical Fibre range. A unique dSCR/legacy TWIN Optical Convertor with high output power, developed to help installers overcome low signal quality in satellite fibre installations.
- TDC5: 5 optical wavelengths are converted to 2 x dSCR/legacy + separate TERR
- Unique product in the market with high output power
- Optical input level: -10 to +2 dBm
- 5 Optical wavelengths: 1310 - 1330 - 1350 - 1370 - 1550nm
- AGC on all output ports
- Signal quality indicator per wavelength
- Sky compatible
- Energy efficient
- Can be used in systems with up to 31 splits
- Power supply: 318165
Optical inputs: 1
RF outputs: 2 x dSCR/legacy + TERR.
Optical wavelengths (nm): 1310 - 1330 - 1350 - 1370 - 1550
Frequency range (MHz): 40 - 694 / 950 - 2150
Optical input level (dBm): -10 to +2
Signal indicator: Green LED per wavelength
dCSS/dSCR UBs: 4 x 16
Output level dSCR (AGC) (dBµV): 85
Output level Legacy (AGC) (dBµV): 78
Output level TERR (AGC) (dBµV): 70
Return loss (dB): -8 (Typ -12)
Input connector type: SC / APC
Output connector type: 75 ohm F type (female)*
Band and polarity selection: DiSEqC 1.0 (unidirectional) | DiSEqC 2.0
(bidirectional) | Standard EN50494/EN50607 | SKY UK protocol | Universal LNB Voltage & Tone
Power consumption (W): 11
Power supply via DC IN (VDC): 12 - 20
Power supply via output (STB) (VDC): 12 - 20
Power indicator: Green LED
Operating temperature range (°C): -10 to +55
Dimensions (mm): 166 x 170 x 50
Weight (kg): 0.430
* Unused ports need to be terminated with 75 Ohm DC-blocked terminator
