TRIAX ECO T5 Adjustable TAP

TRIAX ECO T5 adj tap 1-Way


T5 Adjustable Tap


Main features:
• Satellite and terrestrial Fixed 12dB Tap with 0-18dB adjustable attenuation via a single selector pot. Designed with the latest chipset technology for excellent linearity across all polarities.


ELECTRICAL
Impedance: 75 Ω


CONNECTORS
Number of inputs: 5


FREQUENCY
Frequency range TER: 40...790 MHz
Frequency range SAT: 950...2400 MHz


LOSS
Tap loss TER: TER1: 12...30 (@+/-1dB steps) TER2: 7 dB
Tap loss SAT: SAT1: 12...30 dB
Insertion loss - SAT: 1...2 +/-1 dB
Insertion loss - TER: 1 +/-0,5 dB


OPERATIONAL
LINE power DC voltage (max.): 15 VDC
LINE power current (max.): 35 mA
DC Operating voltage: 15 VDC
DC Current consumption: < 35 mA
PSU/adapter Art number: 318151
Temperature - operating: -20...70 °C


MECHANICAL
Product Length: 160 mm
Product Width: 140 mm
Product Depth: 62 mm
