T.0X (WDM) optical multiplexer
1310 nm/1490 nm - 1550 nm
Passive device that multiplexes/demultiplexes two optical inputs: 1310 nm/1490 nm (GPON), and 1550 nm (RF overlay). For application on G/EPON networks.
The T.0X format frame allows rack installation for optical fibre headends.
MAIN FEATURES
- Low insertion loss
- SC/APC connectors
OPTICAL CHANNEL PERFORMANCE
Working wavelength (nm): 1270…1350 / 1475…1505
Insertion losses (λ) 1310/1490 nm (dB): 0,5
Insertion losses (λ) 1610 nm (dB): ---
Insertion losses (λ) 1550 nm (dB): > 15
Potencia óptica máx. (dBm): +17
Working wavelength (nm): 1540…1565
Insertion losses (λ) 1310/1490 nm (dB): > 25
Insertion losses (λ) 1610 nm (dB): ---
Insertion losses (λ) 1550 nm (dB): 0,7
Potencia óptica máx. (dBm): +22
GENERAL OPTICAL PERFORMANCE
Return losses (dB): > 50
Directivity (dB): > 50
PDL (dB): < 0,1
PMd (ps): < 0,1
Optical conNectors (Type): SC / APC
GENERAL PERFORMANCE
Operating Temp: -5 ... +45 ºC / +23 ... +113 ºF
Protection index (IP): 20
