SAT signal amplification and passive terrestrial signal mixing with low through losses
PIN diode technology SAT attenuator
Power selection switch for LNB: local or remote. In local mode, both band and polarity can be configured using another two switches.
High-screening Zamak chassis
Main features:
- “F” connectors
- SAT equalizer
- Output signal LED indicator
- Test output (-30 dB)
- Can be wall-mounted using screws
Frequency margin: MHz 950... 2150 / 47... 862
Gain: dB 39... 48 / - 1.5
Max.output level: DIN VDE0855/12 /dBμV /> 122
-
Gain adjustment range: dB / 0...30
-
Equalizer dB: 0...15
Vlnb: LOC / mA 300
REM / 500
Vpp: Vpp / 0,6 ± 0,1
Mains voltage (5363 / 536310): V~ / 196 - 254 / 108 - 132
Total AC consumption (5363 / 536310): mA~ max- 130 / 200 - W /13,5 / 14
Protection Level: IP / 20
Temperature operat. limits: ºC / -5 ... +45
