Domestic MATV optical micro-receiver equipped with OLC technology - 1200...1600 nm
Domestic optical micro-receiver; receives one optical signal in the 1200 nm-1600 nm range and restores it on one RF output (47 MHz-1006 MHz), with amplification.
- Equipped with OLC technology
- Perfect for FTTH applications
HIGHLIGHTS:
- Plug & Play: self-regulating
- Low-impact visual design and limited size
- The OLC (Optical Level Control) technology automatically adjusts the parameters to achieve a constant output level, irrespective of the channel load
- Self-controlled output level with an outstanding C/N
- Wide reception optical range
- Integrated high-performance switched-mode power supply: Low power consumption
MAIN FEATURES:
- Provides optical input power information thanks to a LED indicator scale
- SC/APC connectors
- Can be wall-mounted using screws
RF OUTPUT
RF connectors (type): F
Bandwidth (MHz): 47- 1006
Impedance (Ohm): 75
Return losses (dBm) >= 11
Flatness (dB): ± 1,5
Typical level of self-regulated RF output for 41 TV channels (dBμV): 80
CNR (dB): >51
OPTICAL INPUT
Wavelength (nm): 1200-1600
OLC range (dBm): -8 ... +1
Max. optical input power (dBm): 2
Min. input optical power recomm. (dBm): -10
Optical return losses (dB): < 40
Optical input connector (type): SC/APC
Optical device (type): InGaAs pin photodiode
GENERAL
Mains voltage (V~): 196-264
Max. current (mA): 19
Max. power (W): 1,73
Operating temperature: -5 ... +45 ºC
Protection index: IP20
