FiberKom optical mini-receiver equipped with OLC technology
1200...1600 nm
OLC Technology (Remote Powered)
Optical mini-receiver for small MDU (Multi Dwelling Unit); receives one optical signal in the 1200 nm-1600 nm range and restores it on one RF output (47 MHz-1006 MHz) with amplification.
- Equipped with OLC technology
- Perfect for RF Overlay, FTTB, and FTTH applications
HIGHLIGHTS
- The OLC (Optical Level Control) technology automatically adjusts the parameters to achieve a constant output level, irrespective of the channel load
- Equipped with pre-equalization, attenuation, and equalization controls to adapt the output signal to the coaxial network characteristics
- High output voltage (RF amplification) and enhanced C/N
- Wide reception optical range
- Low power consumption
MAIN FEATURES
- SC/APC optical connectors, and F-type connectors for RF
FORWARD PATH
Frequency range (MHz): 47 ... 1006
Output impedance (Ohm): 75
Optical input level for OLC (dBm): -8 ... +1dBm
Flatness (dB): ± 1
Number of outputs (no.): 1
Typical output level in OLC range (dBμV / dBmV): 100 / 40
CNR (dB): >51
CSO (dB): >60
CTB (dB): >60
Equivalent noise current density at input (pA/Hz): < 6
Gain control (2dB steps) (dB): 0... 18
Pre-emphasis (dB): 3, 7, 9
Wavelength (nm): 1200 - 1600
Optical return loss (dB): >40
Optical connector (type): SC/APC
Max. optical input power before damage (dBm): 2
Optical device (type): InGaAs pin photodiode
GENERAL
Power voltage / Max. consumption (V=/mA): 11 / 340.... 35 / 140
Test point (dB): -30 ±1
RF connectors (type): F
Housing material: Zamak/ABS
Operating temperature: -5...+45 ºC / +23....+113 ºF
Index operation (IP): 30
EMC compatibilit: EN 50083-2
Safety: EN 60825-1
