Professional 2 channels relay with Wi-Fi, LAN, and Bluetooth connection, suitable for home and facility automation with remote control. DIN rail mountable insde a breaker box. Enhanced safety features and compatible with most used home automation platforms.
Main features:
- LAN, Wi-Fi, and Bluetooth connection
- 2 output, 16A each. Total device maximum of 25A
- Dry contact
- DIN rail mountable
- 2 phases control
- Power supply AC: 110-240V ±10%, 50/60Hz
- Maximum load: up to 16A per channel with up to 25A for the whole device
- Power supply DC : 12VDC ± 10%
- Channels: 2 Channel
- Device temperature protection
- Overload protection
- Power measurement
- HTTP/HTTPS webhooks
- Custom scripts (mJs)
- Operational temperature: -20°C to + 40 °C
- Device power consumption:< 4 W
- Intelligent On/Off
- Local and remote control
- Sunrise/Sunset
- Weekly Schedule
- Wireless
- Wi-Fi Protocol: 802.11 b/g/n
- Wi-Fi Radio frequency: 2412 - 2484 MHz
- Wi-Fi Radio signal power: 1mW
- Wi-Fi Range: up to 50 m outdoors and up to 30 m indoors (depending on the building materials)
- Bluetooth
- Ethernet
- Size: 18,5mm x89,5mm x 68,5mm
