With the 9774, you can uniquely offer a wide range of video content in multi-dwelling units, because you can reach 4 orbital positions per SCR output. Moreover, you can select for each output a different combination of orbital positions!
Main features:
- 8 satellite + 1 terrestrial inputs, 4 SCR outputs
- 8 satellite wideband inputs and 1 terrestrial input
- Compatible with the following standards: EN50494, EN50607, BSKYB
- Compatible with 4 wideband LNBs
- Compatible with 2 Quattro LNBs
- 4 SCR outputs with each 16 user bands
- 1 terrestrial input
- STB should support dSCR (EN50494), dCSS (EN50607) or BSKYB
- Inputs : SAT: 8 TERR: 1
- Frequency MHz: SAT: 290 - 2340 TERR: 88 - 862
- Input level dBµV SAT-Universal: 58 to 108 / TERR: 100 (amplified)
- Return loss IN/OUT: dB SAT: -10 / TERR: -10
- Insertion loss dB SAT: 2 TERR: 3
- SAT positions: Wideband: 4 / Universal: 2
- Supported LNB types : quattro (LO: 9750/10600) / wideband (LO:10410)
- SCR Outputs : 4
- Trunk Outputs : SAT: 8 / TERR:1
- dSCR channel power dBµV: 86 (AGC controlled)
- Output return loss dB: 10
- Trunk insertion loss dB: SAT.: -2 / TERR: -3
- TERR output loss dB: -20 or -8 (switchable)
- SCR channels (16 users/output): MHz Configurable between 950 and 2150
- Supported standards: EN50494 / EN50607 / BskyB
- Trunk termination DC blocked required: Ohm 75 (SAT & TERR)
- DC supply to SAT trunks from power adapter :V 20
- DC supply from SAT trunks: V 20
- Max LNB current /LNB: mA 500
- DC jack 2,1mm: V 20
- F con DC input: V 20
- DC power from output port
- Consumption :W 24
- Dimensions mm: 220 x 220 x 50
- Operating temperature: °C -20 to 50, indoor housing
