The HDL-MR0410.431 relay module can supply 4 channels with a current of 10A. The module is able to support diversified devices, and can be applied in to any solution which requires switching control.
Zero power consumption:
Using a high performance magnetic launching relay the MR0410.431 does not consume any power in standby mode, and when the module is triggered it only uses a momentary DC Pulse.
Reliable:
Each of the four channels that the module outputs to support 10A. Due to the inclusion of a 16A magnetic relay, the module has a guaranteed stable performance, and lower maintenance requirements. This built in redundancy ensures the module has a long and efficient service life.
Multiple loads:
Thanks to the built in 16A magnetic relay, the module can handle a 500A current surge. This enables the module to switch multiple loads from a wide range of sources. From lighting, heating, motors, transformers, valves and power sockets, this module unifies and streamlines control into one simple to install and operate package.
Power on protection:
All of the modules 4 channels feature a power on protection delay time; this delay time is adjustable from 0-60 minutes. This delay protection safeguards lights that are connected to the module providing a hassle free service and a maximized life expectancy.
Network protection:
In order to protect the power network the MR0410.431, has a delay time from 0-25 seconds. This ensures that the danger posed to the power network by current surges when multiple devices are turned on is negated.
Functions:
- 4-channel relay output unit.
- Scene controller function available.
- Up to 4 separate areas.
- Each area has 8 scenes, maximum running time for scene is 60 minutes.
- Each channel has light protection delay (0-60 minutes).
- Each channel has batch turn-on delay(0-25 seconds).
- Each channel has manual control for relay unit.
- You can select specified scene or scene before power off when the device restarts.
- Supports easy programming and HDL Buspro online upgrading.
- Communication: HDL Buspro.
Electrical Parameters:
- Working power: DC15~30V
- Static power consumption: 15mA/DC24V
- Dynamic power consumption: 40mA/DC24V
- Output channel: 4CH/10A
- Relay: 16A Magnetic latching relay
- Max current in each channel: 10A
- Electronic life time of relay: >60000 (Resistance Load)
- Protection: Connect a breaker in each channel
Approved:
- CE
- RoHS
Product Information:
- Dimensions: 72�90�66 (mm)
- Weight: 252(g)
- Housing material: Nylon, PC
- Installation: 35mm DIN rail installation
