The Blustream HEX11WPW-TX HDMI Wall Plate HDBaseT™ Transmitter is a 4K solution that extends HDMI up to 70m at 1080p (40m 4K 60Hz 4:2:0).
The HEX11WPW-TX has been designed to work with all Blustream HDBaseT™ receiver and matrix solutions, can be installed in both UK and European back boxes, and can be powered locally or from compatible Blustream HDBaseT™ products.
Key Features:
- Advanced HDBaseT™ technology offering distribution of video and audio over a single CAT cable
- Supports 4K UHD video up to 40m (3840 x 2160 @30Hz 4:4:4, 4096 x 2160 @24Hz 4:4:4, and 4K @60Hz 4:2:0)
- Extends HDMI at 1080p up to a distance of 70m
- Smart EDID function automatically limits EDID to within HDBaseT™ specification to improve compatibility
- Supports all known HDMI audio formats including Dolby TrueHD, Dolby Atmos, Dolby Digital Plus and DTS-HD Master Audio transmission
- Supports 12V-48V PoC from compatible Blustream HDBaseT™ receiver / matrix products
- Bi-directional RS-232 pass-through
- Supports IR pass-through to HDBaseT™ device
- Compatible with all Blustream HDBaseT™ receiver / matrix products*
- White magnetic faceplate surround allowing for both UK & EU backbox compatibility
- HDCP 2.2 support
*When the HEX11WPW-TX is powered locally, PoC can be used to power a compatible Blustream receiver. HPD (Hot Plug Detect) is only active when an HDMI source device is connected to the HEX11WPW-TX.
**Technical performance is subject to the features supported on the connected HDBaseT™ device.
Specifications:
- Video Input Connectors: 1 x HDMI Type A, 19-pin, female
- Video Output Connectors: 1 x HDBaseT™ RJ45 connector
- RS-232 Serial Port: 1 x 3-pin Phoenix connector
- IR Input Port: 1 x 3-pin Phoenix connector
- Local Power Input: 1 x 2-pin Phoenix connector
- Module Dimensions (W x H x D): 136mm x 76mm x 44mm (w/o faceplate)
- Faceplate Dimensions (W x H x D): 146mm x 86mm x 6mm
- Cut Out Dimensions (W x H x D): 87mm x 49mm x 39mm
- Mounting Hole Spacing: UK 121mm CTC, EU 60mm CTC
- Backbox Mounting Depth: 40mm (minimum), 47mm (recommended), UK or EU double gang
- Shipping Weight: 1.0Kg
- Operating Temperature: 32°F to 104°F (-5°C to +55°C)
- Storage Temperature: -4°F to 140°F (-25°C to +70°C)
- Power Supply: 12V/1A DC
Box Contents:
1 x HEX11WPW-TX
1 x 12V/1A DC Power Supply
1 x Magnetic Faceplate
1 x Quick Reference Guide
