The Blustream HEX70USB-KIT 4K HDBaseT™ USB 2.0 extender set offers the very best in performance and flexibility, delivering HDMI to lengths of 70m (4K 60Hz 4:2:0 to 40m), USB 2.0 extension, bi-directional IR and RS-232, HDMI audio breakout, bi-directional PoC, and advanced EDID management. HDCP2.2 compliant.
Key Features:
- Advanced HDBaseT™ technology offering uncompressed video and audio with zero latency
- Extends HDMI 1080p up to a distance of 70m over a single CAT cable
- Supports 4K UHD video up to 40m (3840 x 2160 @30Hz 4:4:4, 4096 x 2160 @24Hz 4:4:4, and 4K @60Hz 4:2:0)
- HEX70USB-KIT features 4x USB Type-A devices (RX - peripherals) and 1x USB Type-B (TX - host) that support a combined data transmission bandwidth of up to 280Mbps
- USB Type-A connections support 5V 500mA output per port
- Supports bitstream passthrough of multichannel surround sound including object-based audio formats in line with HDMI specifications
- Bi-directional IR pass-through
- Bi-directional RS-232 pass-through
- Supplied with Blustream IR receiver and emitter
- Supports bi-directional PoC (Power over Cable) to power extenders from either Transmitter or Receiver end
- HDCP 2.2 compliant with advanced EDID management
- HDMI audio breakout to analogue L/R audio and Optical digital (S/PDIF) outputs concurrently
Specifications:
HEX70USB-TX
- Video Input Connectors: 1 x HDMI Type A, 19-pin, female
- Video Output Connectors: 1 x HDBaseT™ RJ45 connector
- RS-232 serial port: 1 x 3-pin Phoenix connector
- USB/KVM Port: 1 x USB Type-B (Host)
- IR Input ports: 1 x 3.5mm stereo jack
- IR Output ports: 1 x 3.5mm mono jack
HEX70USB-RX
- Video Input Connectors: 1 x HDBaseT™ RJ45 connector
- Video Output Connectors: 1 x HDMI Type A, 19-pin, female
- Audio Output Connectors: 1 x Toslink (S/PDIF), 1 x 3.5mm L/R Analogue audio
- RS-232 serial port: 1 x 3-pin Phoenix connector
- USB/KVM Port: 4 x USB Type-A (Peripherals)
- IR Input ports: 1 x 3.5mm stereo jack
- IR Output ports: 1 x 3.5mm mono jack
Casing Dimensions (W x D x H ): 135mm x 105mm x 25mm (TX/RX)
Operating Temperature: 32°F to 104°F (-5°C to +55°C)
Storage Temperature: -4°F to 140°F (-25°C to +70°C)
Power Supply: 24V/1.25A DC, 4-pin DIN connector
Box Contents:
1 x HEX70USB-TX
1 x HEX70USB-RX
1 x 24V/1.25A DC power supply
1 x USB-A to USB-B cable
1 x IRE1 emitter
1 x IRR receiver
1 x Serial Cable - DB9 to 3-pin Phoenix connector
1 x 3-pin Phoenix connector
2 x Mounting kit
