The Blustream HEX100CS-RX HDMI 2.0 4K @ 60Hz 4:4:4 (18Gbps) HDCP 2.2 HDBaseT™ Receiver offers market leading features and outstanding value utilising CSC technology.
The product extends HDMI, Bi-directional IR & RS-232 and Bi-directional PoC up to lengths of 100m (4K to 70m). The Receiver features simultaneous analogue stereo and digital coax audio breakout.
Key Features:
- Advanced HDBaseT™ technology offering distribution of video and audio over a single CAT cable
- Advanced Colour Space Conversion (CSC) supports HDMI 2.0 18Gbps specification including HDR
- Supports 4K 60Hz 4:4:4 UHD video up to 70m
- Extends HDMI 1080p video up to 100m
- Supports all industry standard video resolutions including VGA-WUXGA and 480i-4K
- Supports bitstream passthrough of multichannel surround sound including object-based audio formats in line with HDMI specifications
- HDMI re-clocking to help solve HDMI HDCP, compatibility and handshaking issues
- HDMI audio breakout to analogue L/R audio and coaxial digital outputs concurrently
- Supports bi-directional RS-232 pass-through
- Supports bi-directional IR pass-through
- Advanced EDID management
- HDCP 2.2 compliant
Key Features:
- Audio Output Connectors: 1 x RCA (SPDIF) & 2 x Analogue RCA (Left / Right)
- IR Output Ports: 1 x 3.5mm mono jack
- IR Input Ports: 1 x 3.5mm stereo jack
- RS-232 Serial Port: 1 x DB-9 female
- Video Output Connectors: 1 x HDMI Type A, female
- Video Input Connectors: 1 x HDBaseT™ RJ45 connector
- Power Supply: 12V/2A DC, screw type connector (not supplied)
- Power Consumption: 5.6W
- Unit Dimensions (W x D x H): 113 x 124 x 22mm (without connections)
- Unit Dimensions (W x D x H): 113 x 138 x 22mm (with connections)
- Unit Weight: 0.35kg (excluding accessories)
- Operating Temperature: 32°F to 104°F (0°C to 40°C)
- Storage Temperature: -4°F to 140°F (-20°C to 60°C)
- Mounting Kit Included
Box Contents:
1 x HEX100CS-RX
1 x Mounting Kit
