BLUSTREAM Custom Pro 4 Output HDBaseT™

Board 4K 60Hz 4:4:4 to 40m (1080p to 70m)
5 Year Warranty
*Special Order! NCNR - Check Lead Time*

SKU: PRO-OUT4TL-V2

  Product Documents

BLUSTREAM Custom Pro 4 Output HDBaseT™

Board 4K 60Hz 4:4:4 to 40m (1080p to 70m)
5 Year Warranty
*Special Order! NCNR - Check Lead Time*


The PRO-OUT4TL-V2 output board offers 4x independent HDBaseT™ outputs utilising CSC technology allowing support of HDMI 2.0 4K 60Hz 4:4:4 (18Gbps) HDCP 2.2 signal distribution up to lengths of 70m (4K to 40m).It features independent down-scaling of 4K video inputs on the CSC HDBaseT™ outputs to allow displays only capable of supporting lower video resolutions to receive 4K video while still showing maximum original 4K UHD resolution on the higher-definition displays. It also features quick release card module fittings allowing simple installation into the Custom Pro Matrix hub.

Main features:

  • Advanced HDBaseT™ technology offering distribution of video and audio over a single CAT cable
  • Features 4x HDBaseT™ outputs for connection to compatible HDBaseT™ receivers
  • Advanced Colour Space Conversion (CSC) supports HDMI 2.0 18Gbps specification including HDR support
  • Supports 4K 60Hz 4:4:4 UHD video up to 40m*
  • Independent down-scaling of video input resolutions up to 4K 60Hz 4:4:4 to the following formats: 1080p 60Hz (for screens that do not support 4K) / 4K 60Hz 4:2:0 (for screens that do not support full 4K 60Hz 4:4:4)
  • Extends HDMI 1080p video up to 70m
  • Supports all known HDMI audio formats including Dolby TrueHD, Atmos and DTS-HD Master Audio transmission
  • Supports PoH (PoE) to power Blustream HDBaseT™ Receivers
  • Quick release card module fittings allowing simple population of input and output cards in Custom Pro Matrix Hub
  • HDCP2.2 Support
  • To be used with the HEX70CS-RX receivers
  • For HDMI 2.0 18Gbps video distribution the PRO-OUT4TL-V2 must be used with a HDMI 2.0 18Gbps Custom Pro input board
