The PSF1200 Power Unit from Antiference is designed to inject 12 volts DC onto a coaxial TV aerial cable, in one direction to power a masthead amplifier or similar line powered device with minimal insertion loss.
Main features:
- 12v masthead amplifier up to a maximum 100mA load
- Fully screened
- Female F-connectors
- Fitted with a mains Plug BSI363 3A rating
- Short circuit and overload protected
Mains: 230V AC ± 10% 50Hz Fitted Mains Plug BS1363 3A rating
Power Indicator: Red L.E.D
Line Power Out: + 12V DC (±10%) 100mA
Insertion Loss: <1dB (46-1000MHz)
Screening: EN50083-2
