- Classification : Smart socket
- Device type : Remote-controlled
- Installation method : In outlet
- Compatibility with hubs : All hubs
- Compatibility with range extenders : All radio signal range extenders
- Actuating element : Electromagnetic relay
- Service life : At least 200,000 switches
- Power supply voltage range : 230 V~, 50 Hz
- Output power (resistive load at 230 V) : up to 3 kW
- Device energy consumption : ≤ 1.5 W
- Maximum current protection : Yes, selectable 1-16 A
- Maximum temperature protection : Yes, +85°С : The socket turns off automatically if the temperature is exceed
- Overvoltage protection : Yes, min - 184 V~ max - 253 V~
- Electric shock protection class : Class I (with grounding terminal)
- Energy consumption parameter check : Yes (current, voltage, power consumption, consumed energy)
- Load indicator : Yes
- Maximum load current : 16 A (up to 5 sec)
- Load indicator : Yes : The option of adjusting the brightness of the LED frame of the device (15 brightness values)
- Operation modes ; Impulse : Bistable
- Contact state : Normally open : Normally closed
- LED indication : Adjustable (LED frame, 7 colours)
- Adjustable pulse duration : 0.5 to 255 sec
- Jeweller radio technology : Communication range with the central unit - up to 1,100 m in an open space : Two-way communication between devices : Operating frequencies: 866.0 - 866.5 MHz
868.0 - 868.6 MHz, 868.7 - 869.2 MHz, 905.0 - 926.5 MHz, 915.85 - 926.5 MHz, 921.0 - 922.0 MHz
(depends on the region of sale) : Self-adjusting RF output power - up to 25 mW : Block encryption with floating key : Device authentication, Verification of each communication session
Detector scanning period from 12 to 300 sec
- Anti-sabotage : Protection against forgery : Jamming detection
- Remote setting and testing : +
- Operating temperature range : From 0°С to +40°С
- Operating humidity : Up to 75%
- Ingress protection : IP20
- Overall dimensions : 54.5 × 54.5 × 59 mm (with plug)
- Weight : 90 g
- Warranty : 24 months
- Service Life : 10 Years
