Kordz Keystone RJ45 Sockets perfectly complement Kordz ONE Series Bulk Category Cabling. Featuring a die-cast metal clamshell design and a latching mechanism, Kordz Keystone RJ45 Sockets are very easy to fit. Match them with Kordz PRS Patch Cords for a complete Kordz ecosystem that delivers ‘Connectivity Assured’.
- Die-cast metal clamshell design
- Easy to terminate with latching mechanism
- 6 pieces per pack
- Sturdy and robust shielded construction
- Manufactured with quality materials and using advanced manufacturing methods
Technical Specificatons
General Information
Guaranteed Performance Category: Category 6A
Applicable Standards: ANSI/TIA-568-C.2
Housing material: Zinc Alloy
Flammability Rating: UL 94 V-0
Contact Type Three Prong for Solid / Stranded wires
Contact Material: Copper
Contact Plating IDC: Phospher bronze, Tin Plated
Contact Plating RJ45: Gold Plating 50µ” [1.27µm]
Housing Colour: Transparent
Shielding Type: Shielded
Operating Temperature: -10° to 66°C
MECHANICAL
Keystone Body Length: 37.33mm | 14.7in
Keystone Body Width: 17.10mm | 6.7in
Keystone Body Height: 23.68mm | 9.3in
Panel Mating Height: 16.10mm | 6.3in
Panel Mating Width: 14.50mm | 5.7in
Electronic
Voltage/Current rating UL Applications: 125 Volts AC / 1.5 Amps
Dielectric Withstanding Voltage: 1500 Volts DC / AC Peak
Contact Resistance: ≤ 20mΩ
Insulation Resistance: ≥ 500MΩ
RJ45 Cycle: 750 times
Insertion IDC: 20 times
Wire Gauge min/max: min: 26AWG / max: 23AWG
Conductor Diameter: max:8.5mm Ø
Cable Jacket Diameter max: 6.5mm Ø
