The Kordz ONEv2 HDMI Cable is the professional grade passive HDMI cable designed to provide reliable, economical, uncompressed 4K connectivity for high volume commercial integration projects.
It delivers full 18Gbps performance at every length up to 5m.
Its slim, flexible, fire-rated PVC jacket and compact connector ensure durability, easy routing and secure connections, even in tight spaces.
Supplied in eco-friendly recyclable paper packaging, the ONEv2 HDMI Cable is quick to open, easy to clean up, and comes backed by the Kordz lifetime warranty for peace of mind.
Product Outline:
- Full 18Gbps bandwidth for reliable uncompressed 4K signal at all lengths up to 5m
- Compact connector assembly rated for 1kg retention force
- Flexible, slim, fire-rated PVC jacket for easy installation in tight spaces
- Supplied in eco-friendly recyclable, quick-to-open paper packaging with hang tab
- Individually tested for consistent performance that’s ‘Connectivity Assured’
- Designed for economical, high-volume commercial integration projects
- Lifetime warranty for peace of mind
Application:
Data Rate: Up to 18.2Gbps (TMDS mode)
Video Resolution: Up to 8K (7680 x 4320) / 10K (10240 x 4320)
Video Refresh Rate: Up to 240 frames per second
Colour Depth: Up to 16 bits
Colour Formats: RGB 4:4:4 / Y’CBCR 4:2:2 / Y’CBCR 4:2:0
Content Protection: Up to HDCP 2.2 supported
Audio Sample Rate / Channel: Up to 192KHz
Audio Sample Size: Up to 24 bits
Audio Channels: Up to 32 channels
Audio Formats Supported: DTS Master, DTS:X, Dolby TrueHD, Dolby Atmos
Auxiliary HDMI Features Supported: Consumer Electronic Control (CEC), Auto Lip-Sync Correction, Ethernet channel, Audio Return Channel (ARC), Enhanced Audio Return Channel (eARC), High Dynamic Range (HDR)
Technical Information:
HDMI CERTIFICATION – 0.5m – 5.0m Lengths
HDMI CTS (Certified Test Specification): High Speed with Ethernet
Certified Data Rate: 6.0Gbpsc, 17.82Gbps agg
Supported Data Rate: ≥ 6.0Gbpsc, 17.82Gbps agg (4K UHD)
MECHANICAL
Cable Diameter: 0.5m-3.0m: 5.10±0.15mm/0.201in Ø | 4.0m-5.0m: 6.50±0.15mm/0.256in Ø
Mounting Depth: 0.5m-3.0m: 20.0mm/0.79in Ø | 4.0m-5.0m: 22mm/0.87in Ø
Cable Bend Radius: 0.5m-3.0m: 25.50mm/1.00in Ø | 4.0m-5.0m: 32.50mm/1.28in Ø
Retention Force (nominal): 1kgf / 10N (nominal)
CONSTRUCTION
Primary Conductors: 0.5m-3.0m: Solid 32AWG OFC | 4.0m-5.0m: Solid 28AWG OFC
Insulation: Polypropylene
Shielding on TMDS Pairs: Al / Mylar, 125% coverage
Shielding Overall: Al/Mylar, 125% Coverage + Al-Mg Braid 65% Coverage
Cable Jacket: 0.5 – 2.0m: VW-1 | 3.0 – 5.0m UL CMG fire-rated PVC composite materials
HDMI Connector Shell: Premium gauge folded steel, 1μ” Ni-plated
HDMI Connector Pins: Solid OFC, 15μ” 24K Gold plated
Termination: High Frequency Soldering
Connector Assembly: PVC glossy front shell with PVC injection moulded boot and strain relief
