These SC/APC fast connectors are factory pre-polished, field-installable connectors that completely eliminate the need for hand polishing in the field. Using proven mechanical splice technology. A factory pre-cleaved fibre stub combined with index-matching gel provides an immediate low-loss termination.
Note: If 2.0 mm or 3.0 mm OD connections are required, simply remove the 0.9 mm adaptor from the fast connector.
Specifications:
Description: SC/APC Fast Fit
Insertion Loss: ≤0.3dB (MA*0.5dB)
Return Loss: ≥60dB
Fibre Diameter (mm): 2.0, 3.0, 3.5 GJXH
Tension: 20N
Operating Temp.: -40°C ~ 85°C (≤0.5dB)
