The Ubiquiti NanoSwitch is a small 4-port outdoor unmanaged switch designed for pole deployment where there might be multiple Ubiquiti devices requiring Passive PoE power and Data. The NanoSwitch is ideal for use with Ubiquiti airMax and Unifi Video cameras.
Power Strip Simplicity for 24V Devices - Simply providing 24V 2-pair input makes NanoSwitch an outdoor 4-port unmanaged switch with "always on" 24V 2-pair output on three ports.
PoE Passthrough;
PoE In - RJ45 port supports 10/100/1000 Ethernet connections, and supports passive 24V, 2-pair PoE to power the switch.
PoE Out - RJ45 ports support 10/100/1000 Ethernet connections, and the three passive 24V, 2-pair PoE ports provide up to 24W PoE output.
Designed for Outdoor Durability - The NanoSwitch features an outdoor weatherproof form factor. Operating Temperature: -30 to 70� C (-22 to 158� F)
Specifications:
Dimensions: 196.4 x 93.5 x 32.4 mm
Weight: 271 g
Power Supply: POE-24-24W (Not Supplied)
Max. Power Consumption: 1.5W
Power Method: Passive PoE (2-pair PoE In)
Passive PoE Max. Wattage per Port: 24V, 2-Pair, 1A per Port (24W)
Total Passive PoE Max. Wattage: 24V, 2-Pair, 1A for 3 Ports (24W)
Networking Interface: 4 x 10/100/1000 Mbps Ethernet Port
Total Non-Blocking Line Rate: 4 Gbps
Mounting: Pole-Mount (Kit Included)
Operating Temperature: -30 to 70C
Operating Humidity: 5 to 95% Noncondensing
ESD/EMP Protection: +-24kV Contact/Air
Shock & Vibration ETSI300-019-1.4
Certifications: CE, FCC, IC
