Please Note: The EdgeSwitch 5-Port only supports 24V devices. This will not be compatible with any device requiring 48V. If you require support for 48V, we recommend the EdgeSwitch 8-Port.
The Ubiquiti EdgeSwitch PoE is a 5-port Gigabit switch with 24V PoE support for each port. The EdgeSwitch 5-Port is a cost effective solution, perfectly designed for powering a number of Ubiquiti products including the airMAX, the UniFi, and airVision devices.
Key Features:
Ports - 5 Gigabit PoE
PoE - 24V Configurable Passive
EdgeSwitch PoE Configuration Interface
Wall-Mountable
Product Model Number: TS-5-PoE
General:
Dimensions:197 x 87.5 x 27.3 mm
Weight: 250g
Power Input: 24VDC, 2.5A Power Adapter (Included)
Max. Power Consumption: 60 W
PoE Out Voltage Range: 22-24VDC
Max. PoE Wattage Per Gigabit Port: 18 W
ESD Rating: 24 kV Air / 24 kV Contact
PoE Method: Passive
Button Reset
USB Port 2.0 Type A (Reserved for Future Use)
Processor: MIPS24K 400 MHz
System Memory: 64 MB
Code Storage: 8 MB
Certifications: CE, FCC, IC
Wall-Mount: Yes
Operating Temperature: -25 to 55°C (-13 to 131° F)
Operating Humidity: 90% Non-Condensing
PoE Configurable Per Port
Management: N/A
Ports 1-5 Off/24V
LEDs Per Port
Management Link/Activity
Ports 1-5 PoE, Speed/Link/Activity
Networking Interfaces
Management Port (1) 10/100 Ethernet Port
Ports 1-5 (5) 10/100/1000 Ethernet Ports
