Ubiquiti IsoStation AC is Ubiquiti Networks latest generation of airMAX AC sectors with dedicated Wi-Fi management and built in radio. The IS-5AC is specially designed for cluster installations where low side lobe radiation and low back radiation are key.
Please note, this item includes the 45 degree antenna (as pictured) HORN-5-45, if you require a different antenna see codes HORN-5-30, HORN-5-60 and HORN-5-90
Using airMAX AC technology, the IsoStation 5AC supports up to 450+ Mbps real TCP/IP throughput. It also offers the following features:
Interchangeable horn antennas for enhanced beam shaping.
Horn feed comes directly from the radio input/output so connectors are eliminated.
Single button release for ease of changing antennas.
All metal, shielded radio base.
Metal strap for quick pole-mounting.
Ubiquiti offer four optional antennas with precise radiation angles for specific beam shaping, so you can customise the IsoStation 5AC for your specific installation requirements:
30°
45°
60°
90°
Improved Noise Immunity - The IsoStation 5AC provides high isolation solutions in fixed beam-width increments through interchangeable horn antennas that have been optimised for urban environments. The tailored antenna radiation patterns spatially filters both in-band and out-of-band spurious RF emissions to increase the noise immunity of the IsoStation 5AC. This feature is especially important in an increasingly congested RF environment.
Modular Design - With flexible sectorisation for optional antenna beam-widths, the horn antenna is interchangeable and improves beam-shaping for specific deployment and environment needs. The IsoStation 5AC uses horn antenna sectors designed for increased co-location performance without sacrificing gain.
Symmetrical Antennas - Symmetrical horn antennas (30 and 45 Degree versions) offer breakthrough scalability options for wireless systems. They are ideal for cluster sector installations with high co-location requirements. Unique beam performance and great co-location characteristics allow for a higher density of sectors than traditional sector technology.
Asymmetrical Antennas - Asymmetrical horn antennas (60 and 90 Degree versions) are designed to have attenuated side lobes and extremely low back radiation.
