Triax FM/DAB/UHF/SAT DC Combiner - External.
4 In 1 Out
- Masthead Combiners with gold F Connectors
- Greater electrical connectivity
- Improves shielding
- Corrosion resistant
- Flip and lock mechanism for easy installation
- Neoprene soft cable grip
- Weatherproof housing
- Full screened enclosure
- Field proven mast securing methods
- Supplied with F-Connector tool
FREQUENCY
Input 1 - band: FM
Input 1 - frequency: 87.5-108 MHz
Input 2 - band: DAB
Input 2 - channels: 5-12
Input 2 - frequency: 174-230 MHz
Input 3 - band: UHF
Input 3 - channels: 21-68
Input 3 - frequency: 470-862 MHz
Input 4 - band: SAT
Input 4 - frequency: 950-2150 MHz
LOSS
Input 1 - through loss: <1.0dB Typ dB
Input 2 - through loss: <1.5dB Typ dB
Input 3 - through loss: <2.0dB Typ dB
Input 4 - through loss: <3.5dB Ty dB
OPERATIONAL
DC Passthrough: Yes (12VDC / 500mA)
CONNECTORS
Connector Type: F-female
Number of inputs: 4
Number of outputs: 1
MECHANICAL
Height (mm): 140 mm
Depth (mm): 60 mm
Width (mm): 118 mm
