The IP output module is an output module for transmission of digital video, audio and miscellaneous data, encapsulated within one or more MPEG2/DVB single program transport streams.
Main features:
- The TDX headend system provides the following functionality when the IP out module has been installed:
- IP multicast streaming (UDP streaming)
- RTP option
- IGMP version 2
- SPTS including SDT, PAT, PMT, CAT
- Packet ratio of 3-7 TS packet per IP packet ratio 3-7:1
- Max. BW 720 Mbits/s output per IP output module
- 78 services per IP output module/AUX socket
- Possible to change service ID (SID)
- Possible to select from IP via Link
- 2 x CI slots complying EN 50 221
- The backend module package consist of:
- IP output module
- Auxiliary board
- SFP transceiver RJ45 - copper
ELECTRICAL
Impedance: 75 Ω
OPERATIONAL
Output protocol: 3-7:1 TS / IP packet ratio (configurable via GUI), RTP (optional via GUI)
CI slots: 2
DC Operating voltage: 12 ± 1 VDC
DC Current consumption: < 600 mA
Temperature - operating: -10...50 °C
Temperature - storage: -20 ..70 °C
Humidity - operating: 20 ... 80 %
Humidity - storage: 10 ... 90 %
MECHANICAL
Dimensions product (H x D x W): 24 x 162 x 185 mm
Weight (kg) TB(D): 0.22 kg
