TDH 800. Technology, that can do more
The cabinet is designed as one system of input and output signals, as such up to 24 PAL programmes or 24 QAM channels are possible; it is extremely compact and can therefore be easily installed on a wall or in a 19 "rack. Whether it is related to the installation, maintenance or repair all inputs, outputs and cables can be easily installed and operated from the front of the TDH 800.
The HF output level of the integrated TDH 800 output amplifier can be software-adjusted within the range 85 dBµV through 93 dBµV
CHARACTERISTICS
Max. LNB control:4 x 305 mA
Output level max. @ 60 dB IMD - 24 combined channels 93: dBµV
FREQUENCY
Frequency range (RF OUT): 47-862 MHz
MECHANICAL
Dimensions product (H x D x W):265 x 240 x 440 (6,5 HE) mm
OPERATIONAL
AC Supply voltage: 190-260 (50/60 HZ IEC320 1.8m cable) VAC
Power Consumption (typ.): 280 (min 20) W
Temperature - operating: -10...50 °C
Temperature - storage: -20 ..70 °C
Humidity - operating:20 to 80 %
Humidity - storage 10 to 90 %
RETURN LOSS
Return loss (RF OUT): > 10 dB
ELECTRICAL
Impedance: 75 Ω
CONNECTORS
External RF OUT: F-connector
PC interface: RJ 45
