Avoid signal disruption, with Triax's @700 MHz LTE protected aerials.
This aerial will protect against 4G signal disruption, ensuring problem-free TV & Radio reception where LTE is being rolled out in the 700 MHz band.
MAIN FEATURES
- Interference protection from LTE 700 & 800 signals
- Quick and easy installation with semi-assembled aerials
- Mechanical filtering for higher gain
- Corrosion and weather proof dipole housing
- Exceptional build quality and durability
- Reliable high-quality aerial secures end-consumer satisfaction
- Designed to receive DTT signals in the 470...694MHz range
CHARACTERISTICS
Type.: Digi 18
FREQUENCY
Band: B IV/V UHF
Channels: 21...48
Frequency range: UHF 470...694 MHz
LTE protection: 700
GAIN
Gain 14 max dBi
Gain @ 474 MHz (Ch. 21): 11.3 dBi
Gain @ 602 MHz (Ch. 37): 12.5 dBi
Gain @ 694 MHz (Ch. 48): 10.7 dBi
LOSS
Rejection @ 758 MHz (Ch. 56): 8.0 dB
Rejection @ 788 MHz (Ch. 60): 8.9 dB
ELECTRICAL
Front to back ratio - horizontal: 25 dB
CONNECTORS
Connector Type: F-female
MECHANICAL
Elements: 17
Windload: 59 N
Beamwidth horizontal: ±25 °
Bracketry: Cradle/support boom
Main material: Aluminium
Product Length: 1414 mm
Product Width: 480 mm
