The TP-LINK Omada 32 Port 10GE L2+ Managed Switch with 24-Port PoE++ is a crucial tool for installers in building high-performance wired networks. It offers superior speed via its various port options, and its centralised cloud management is designed simplifying monitoring tasks for professionals.
Key Selling Features:
• 770 W total PoE budget enabling speedy data transmissions
• Centralised cloud management for both web and Omada application
• Independent management via Web, CLI, SNMP, and RMON
• Improved efficiency via Static Routing
• Tough metal casing and capability for rack-mounting
Tech Spec:
• 24× 1/2.5/5/10 Gbps RJ45 PoE++ ports and 8× 1/10 Gbps SFP+ slots
• Power Supply rated at 100-240 V AC~50/60 Hz
• PoE Ports (RJ45) conform to the Standard: 802.3bt/at/af
• Dimensions: 17.3 × 13.0 × 1.7 inches (440 × 330 × 44 mm)
• Maximum power consumption: 1,010.2 W (110V/60Hz with 770 W PD connected)
• Max heat dissipation: 3,444.7 BTU/hr (110V/60Hz with 770 W PD connected)
• Switching capacity: 640 Gbps
• Packet Forwarding Rate: 240 Mpps
• MAC Address Table Size: 32 K
• Jumbo Frame capacity: 9 KB
• Quality of Service functionality includes 8 priority queues and 802.1p CoS/DSCP priority
• Advanced Features include batch processing and intelligent network monitoring
• VLAN Group capacity: Max 4K
• Security comprises IP-MAC-Port Binding, DoS Defend, 802.1X, and Port Isolation
• PV6 features include Multicast Listener Discovery (MLD) Snooping, IPv6 ACL, Static IPv6 Routing
• Centralised management via Omada Cloud-Based Controller and Software Controller
The TP-LINK Omada 32 Port 10GE L2+ Managed Switch with 24-Port PoE++ can significantly enhance the efficiency and performance of your wired network. Its comprehensive features are designed to facilitate centralised management and top-tier security.
