TELEVES Fibre IRS Quad GTU MK3

(May require a PSU: D000342)
2 Year Warranty

SKU: 236903

  Product Documents

TELEVES Fibre IRS Quad GTU MK3

(May require a PSU: D000342)
2 Year Warranty


Important Installer Note:
The MK3 GTU’s MUST have a live fibre signal going into them before you connect the power supply!
----------------------------------------------------------------------------

Optical converter to RF Quad
FM/DAB/UHF/SAT

This accessory for systems equipped with an optical LNB, receives an optical TV signal (1100 nm-1650 nm) and restores the original RF signal. Provides 4 RF outputs, with Terr. + SAT combination signal on each connector.

HIGHLIGHTS

  • Switch for satellite gain regulation with three different levels: low, medium and high
  • RF signal presence LED indicator
  • Accepts terrestrial TV signal mix (FM/DAB/UHF)
  • Limited size

MAIN FEATURES

  • FC/PC optical connectors, F-type connectors for RF

SATELLITE
Horizontal High Band (MHz): 1100 - 2150 ≥15.5V + 22KHz
Vertical High Band (MHz): 1100 - 2150 ≤14.5V + 22KHz
Horizontal Low Band (MHz): 950 - 1950 ≥15.5V
Vertical Low Band (MHz): 950 - 1950 ≥15.5V
Return Loss (dB): ≥ 10
Nominal Impedance (Ω): 75
Gain Variation Across Band (dB): ≤ 7
Terrestrial Rejection (dB): 30
Typical Outputs Levels (dBμV): 70

FM / DAB / TDT
RF Frequency Range (MHz): 88 - 790 / FM 88 - 108 / DAB 174 - 240 / DTT 470 - 790
Return Loss (dB): ≥ 10
Nominal Impedance (Ω): 75
Gain Variation Across Band (dB): ≤ 5
Satellite Rejection (dB): 20

Typical Outputs Levels:
1 Multiplex: FM/DTT 76 dBμV / DAB 64 dBμV
6 Multiplexes: FM/DTT 71 dBμV / DAB 60 dBμV

OPTICAL
Optical Wavelength (nm): 1100 to 1650
Optical Return Loss (dB): 45
Optical Input Power: Min. - 15 dBm / Max. 0 dBm

ELECTRICAL
Power Supply Voltage (V): 10 to 20 by AC/DC adaptor or Set Top Box
Current Consumption (mA): 230 @ 10V (RX1 and RX2) 230 @ 10V (RX3 and RX4)

MECHANICAL
Temperature ranges: Operating -15 ... +55 ºC / Storage -20 ... 70 ºC
Optical Input (Typ): FC / PC
RF Output connectors (Typ): 4 x F- female
