OVERVIEW
The Origin Acoustics LCR39 is the flagship model in the Composer LCR range, engineered for high-performance home cinema installations where maximum output, dynamic range and vocal clarity are essential.
Featuring dual 9" glass fibre woofers, a dedicated 4" glass fibre midrange and a 1" aluminium dome tweeter, the LCR39 delivers reference-level cinema performance whilst maintaining a discreet architectural appearance. Designed for premium media rooms, dedicated cinemas and acoustically transparent screen installations, it provides the scale and authority required for larger rooms and high-end AV projects.
KEY FEATURES
• Flagship Composer LCR loudspeaker
• True 3-way speaker design
• Dual 9" glass fibre woofers
• 4" glass fibre midrange driver
• 1" aluminium dome tweeter
• High sensitivity design
• Slim architectural profile
• Horizontal or vertical installation
• Ideal for behind-screen installations
• Paintable magnetic grille
• High-output cinema performance
TECHNICAL SPECIFICATIONS
Driver Configuration:
• Tweeter: 1" Aluminium Dome
• Midrange: 4" Glass Fibre
• Woofers: Dual 9" Glass Fibre
Performance:
• Frequency Response: 35Hz – 20kHz
• Nominal Impedance: 8 Ohm
• Sensitivity: 92dB
• Recommended Amplifier Power: 50 – 250 Watts RMS
DESIGN ADVANTAGES
The larger dual 9" woofer configuration provides:
• Greater bass extension
• Higher output capability
• Improved dynamic range
• Reduced distortion at high volumes
• Better performance in larger rooms
• More impact during movie playback
INSTALLATION DATA
Applications:
• Left Channel
• Centre Channel
• Right Channel
Installation Options:
• Behind acoustically transparent screens
• Media wall systems
• Dedicated cinema rooms
• Premium living room cinemas
• On-wall installation
• In-wall integration
Grille:
• Magnetic low-profile grille
• Paintable finish
INSTALLER NOTES
Recommended Applications:
• Dedicated home cinemas
• Large media rooms
• Luxury residential projects
• Reference cinema systems
• High-performance AV installations
• Dolby Atmos systems
Placement Guidance:
• Ideal behind acoustically transparent projection screens
• Suitable for rooms where cinema reference levels are required
• Position centre channel directly behind screen centre where possible
• Match with Origin Acoustics subwoofers for full-range performance
• Pair with Director Series ceiling speakers for Atmos height channels
Origin Technologies
True 3-Way Architecture
The dedicated midrange driver handles the critical vocal frequencies independently from the bass drivers, resulting in clearer dialogue, improved detail retrieval and greater intelligibility during demanding movie soundtracks.
Glass Fibre Driver Technology
The rigid glass fibre cones maintain accuracy under high power conditions while minimising unwanted resonance and distortion.
High Sensitivity Design
With a sensitivity of 92dB, the LCR39 produces higher output from the same amplifier power, making it ideal for larger rooms and reference-level cinema systems.
Why Installers Like It
The LCR39 gives installers a genuine cinema speaker without the visual impact of large floor-standing loudspeakers. It is particularly effective behind acoustically transparent screens, where it can deliver commercial cinema-style performance whilst remaining completely hidden from view.
For larger media rooms and dedicated cinemas, the LCR39 provides the scale, dynamics and bass authority often missing from smaller architectural speakers.
