OVERVIEW
The Origin Acoustics LCR65 is a premium in-wall loudspeaker designed for installers seeking exceptional music and cinema performance from a discreet architectural speaker. Part of the Director Collection, the LCR65 combines advanced driver technology, high output capability and precise imaging to create an immersive listening experience for both stereo and home cinema applications.
Featuring dual 6.5" glass fibre woofers, a dedicated 4" glass fibre midrange and a 1" DPSD™ silk dome tweeter, the LCR65 delivers powerful bass, outstanding dialogue clarity and excellent dynamic performance while remaining virtually invisible once installed.
KEY FEATURES
• True 3-way in-wall loudspeaker
• Dual 6.5" glass fibre woofers
• 4" glass fibre midrange driver
• 1" DPSD™ silk dome tweeter
• Suitable for Left, Centre or Right channel duties
• Ideal for stereo music systems and home cinemas
• Pivoting midrange and tweeter assembly
• Magnetic paintable grille
• Slim architectural design
• High sensitivity performance
TECHNICAL SPECIFICATIONS
Driver Configuration:
• Tweeter: 1" DPSD™ Silk Dome
• Midrange: 4" Glass Fibre
• Woofers: Dual 6.5" Glass Fibre
Performance:
• Frequency Response: 40Hz – 20kHz
• Nominal Impedance: 6 Ohm
• Sensitivity: 90dB
• Recommended Amplifier Power: 50 – 150 Watts RMS
INSTALLATION DATA
Application:
• Left Channel
• Centre Channel
• Right Channel
• High-performance stereo systems
Mounting:
• In-wall installation
• Portrait or landscape orientation
Grille:
• Magnetic micro-bezel grille
• Paintable finish
INSTALLER NOTES
Recommended Applications:
• Media walls
• Living room cinema systems
• Dedicated home cinemas
• Stereo music rooms
• Multi-purpose family rooms
• Luxury residential installations
Placement Guidance:
• Install at ear height where possible
• For centre channel use, position directly above or below the display
• Suitable for use behind acoustically transparent screens
• Match with Director Series surrounds and ceiling speakers for complete cinema systems
• Pair with a dedicated subwoofer for full-range cinema performance
Origin Technologies
DPSD™ Tweeter
Origin's patented Dual Plane Stabilised Diaphragm tweeter delivers wider dispersion, lower distortion and improved high-frequency detail compared to traditional silk dome designs.
True 3-Way Design
The dedicated midrange driver handles the critical vocal frequencies independently from the bass drivers, resulting in clearer dialogue, improved detail and greater realism for both music and movies.
Glass Fibre Drivers
Glass fibre cones provide an excellent balance of rigidity and damping, delivering accurate bass reproduction while minimising unwanted resonance and distortion.
Pivoting Midrange and Tweeter Assembly
The midrange and tweeter can be aimed towards the listening position, helping installers optimise performance when speaker placement is dictated by room layout or screen location.
Why Installers Like It
The LCR65 delivers genuine high-end performance without requiring floor-standing speakers or bulky cabinetry. It is equally at home in media wall projects, dedicated cinemas and premium stereo installations, offering installers a versatile solution that satisfies both performance and aesthetic requirements.
Its combination of a true 3-way design, dual bass drivers and pivoting driver assembly allows it to outperform many conventional in-wall speakers, particularly when dialogue clarity and musical accuracy are priorities.
