HDL BUS and KNX-EIB Interface Converter

*REDUCED TO CLEAR* *SAVE 50%*

SKU: HDL-MCEIB.231

  Product Documents

HDL BUS and KNX-EIB Interface Converter

*REDUCED TO CLEAR* *SAVE 50%*


The HDL-MCEIB.231 supports two way communications between the HDL Buspro system and the KNX/EIB system. The module can control up to 254 targets, switch scenes, switch channels, and dim channels. The unit can be installed on 35mm DIN rails and uses a working voltage of DC 15-30v.

Conversion between Buspro and KNX/EIB:
The ability to seamlessly convert between Buspro and KNX/EIB protocols, gives users the ability to synchronize and connect a multitude of devices. With this system flexibility users can quickly and easily enhance their existing automation solutions, or simply pick the products and devices that are best suited to meet their needs.

Up to 254 supported targets:
With 254 supported targets the HDL-MCEIB.231 is capable of meeting the most rigorous user requirements. Control over scenes and channel switching/dimming is possible, as is curtain control. These features are enhanced by the ability to broadcast scenes, channel switching, and channel dimming. The conversion of HVAC signals to Buspro or KNX/EIB protocols ensures that a user is always able to maintain a comfortable temperature, or change it with convenience.

Functions:

  • Support various Data Point
  • Two-way communication for HDL Buspro and KNX/EIB
  • Controls up to 254 targets

Electrical Parameters:

  • HDL-BUS input voltage: DC15~30V
  • HDL-BUS input current: 5mA/DC24V
  • KNX/EIB input voltage: DC21~30V
  • KND/EIB input current: <6mA
  • Communication: HDL Buspro, KNX/EIB
  • Software programming: HDL Buspro Setup Tool

Approved:

  • CE
  • RoHS

Product Information:

  • Dimensions: 72�90�66 (mm)
  • Weight: 174(g)
  • Housing material: Nylon, PC
  • Installation: 35mm DIN rail installation
  • Protection degree: IP20
