The SD500M is a monitored surface double maglock with a holding force of up to 500kg on each side. By including two magnets, not only is the holding force doubled for a high-security solution, but the risk of door flexing is also significantly reduced, as the holding force is spread over a greater area. The SD500M is supplied with security catch ropes, which prevent the magnets from falling and ensure they can be mounted safely.
Key features
- Double electro-magnetic lock
- 500kg per side for a total 1 metric ton of holding force
- Monitored with LED indication
- Rounded edges & safety ropes to ensure safer installation
- Premium quality magnetic locks - robust security for your projects
Dimensions
Product Height (mm) - 532
Product Width (mm) - 66
Product Depth (mm) - 40
Armature Plate Dimensions (LxWxH) - 185 / 60 / 12 mm
Product Weight (kg) - 5.7
