The Blustream DA11USB-V2 has been designed to both encode 2ch USB audio to a Dante® digital signal, and decode a Dante® digital signal to 2ch USB audio.
It features both USB Type-B and USB-C connections selectable via local dip-switch and is a plug & play device that is powered using PoE (Power Over Ethernet) or via 5V from the USB device.
The DA11USB-V2 also supports AES67 RTP audio transport.
Key Features:
- Encodes 2ch USB audio to Dante® digital signal
- Decodes a Dante® digital signal to USB audio
- Selectable USB audio between USB Type-B and USB-C inputs
- Compliant with USB Audio Device Class Specification V2.0
- USB Audio Supports 44.1, 48, 88.2, 96, 176.4 & 192 KHz sample rates @ 16, 24 & 32 Bit
- Dante® Audio Supports 44.1, 48, 88.2 & 96 KHz sample rates @ 16, 24 & 32 Bit
- Configurable Dante® device latency (supports 2, 3, 4, 5 or 10ms configurable using Dante® Controller)
- Supports AES67 RTP audio transport
- Features Class 0 IEEE 802.3af PoE for powering of product from any PoE switch
- Supports power via 5V USB for when network switch does not support PoE
Dante® is a registered trademark of Audinate Pty Ltd
Specifications:
- Audio Input Connectors: 1 x RJ45, female (100Mbps Dante® network), 1 x USB Type B female, 1 x USB Type C female
- Audio Output Connectors: 1 x RJ45, female (100Mbps Dante® network), 1 x USB Type B female, 1 x USB Type C female
- Casing Dimensions (W x H x D): 120mm x 26mm x 47mm without feet
- Operating Temperature: 32°F to 104°F (0°C to 40°C)
- Storage Temperature : -4°F to 140°F (-20°C to 60°C)
- Power Supply: Class 3 IEEE 802.3af PoE or 5v USB
Box Contents:
1 x DA11USB-V2
1 x USB-A to USB-B 1m cable
1 x USB-C to USB-C 1m cable
1 x Quick Reference Guide
