The Blustream DA11USB has been designed to both encode 2ch USB audio to a Dante® digital signal, and decode a Dante® digital signal to 2ch USB audio.
It features both USB Type-B and USB-C connections, selectable via a switch, and is a plug & play device that is powered either using PoE (Power Over Ethernet), or with 5V from the USB device. The DA11USB also supports AES67 RTP audio transport.
Key Features:
- Encodes 2ch USB audio to Dante® digital signal
- Decodes a Dante® digital signal to 2ch USB audio
- Selectable USB audio between USB Type-B and USB-C inputs
- Compliant with USB Audio Device Class Specification v1.0
- Supports 44.1, 48, & 96KHz sample rates @ 24 Bit
- Configurable Dante® device latency (supports 1, 2 or 5ms configurable using Dante® Controller)
- Supports AES67 RTP audio transport
- Features Class 3 IEEE 802.3af PoE for powering of the product from a PoE switch
- Supports power via 5V USB for when network switch does not support PoE
Dante® is a registered trademark of Audinate Pty Ltd
Specifications:
- Audio Input Connectors: 1x RJ45, female (100Mbps Dante® network), 1x USB Type B female, 1x USB Type C female
- Audio Output Connectors: 1x RJ45, female (100Mbps Dante® network), 1x USB Type B female, 1x USB Type C female
- Casing Dimensions (W x H x D): 120mm x 26mm x 47mm
- Operating Temperature: 32°F to 104°F (0°C to 40°C)
- Storage Temperature : -4°F to 140°F (-20°C to 60°C)
- Power Supply: Class 3 IEEE 802.3af PoE, or 5V USB
Box Contents:
1 x DA11USB
1 x USB-A to USB-B cable - 1m
1 x USB-C to USB-C cable - 1m
1 x Quick Reference Guide
