This HDMI 2.0 Multicast distribution platform allows virtually latency free (1 frame) distribution of HDMI video over a 1GB Network switch. The IP300UHD-WP Transmitter is an industry leading 4K HDMI 2.0 HDCP 2.2 transmitter that using visually lossless compression technology delivers switchable HDMI or USB-C, Bi-directional RS-232 & USB/KVM up to lengths of 100m over standard network architecture.
The IP300UHD-WP can be powered via PoE from the network switch or locally should the switch not support PoE. The IP300UHD-WP is compatible with the IP300UHD-TX/RX and IP350UHD-TX/RX products and with multiple configuration options available, the Multicast solution is ideal for both commercial and residential installations.
Key Features:
- Advanced 4K HDMI 2.0 video over 1Gb Network
- Virtually unlimited system size
- Extends HDMI / USB-C up to a distance of 100m over a single CAT cable
- Manual and / or auto source switching of inputs
- Supports up to 4K UHD 60Hz 4:4:4
- Supports HDR, HDR10+ & Dolby Vision
- Supports all known HDMI audio formats including Dolby Atmos, Dolby TrueHD, Dolby Digital Plus and DTS-HD Master Audio transmission
- Advanced signal management for independent routing of RS-232, USB/KVM, audio and video
- PoE (Power over Ethernet) to power Blustream products from PoE switch
- Local 24V power supply (should Ethernet switch not support PoE)
- HDCP 2.2 compliant with advanced EDID management
- Compatible with Blustream IP300UHD-TX/RX and IP350UHD-TX / RX products
- Dual US Decora faceplate surround and backbox compatibility
- The IP300 Series Multicast system features flexible deployment options including:
- Matrix distribution (requires 1Gb network switch)
- Video wall (requires 1Gb network switch)
- One-to-one HDMI extender (no network switch required)
- One-to-many HDMI extender (no network switch required)
