The Blustream ARC11 has been designed to extract audio from the HDMI ARC (Audio Return Channel) of a display.
Featuring both an analogue audio, and optical audio output, it can extract the embedded ARC audio information for use within a multi room audio distribution system.
Key Features:
- Extracts audio from the Audio Return Channel of a HDMI signal*
- Features analogue audio breakout of 2ch PCM audio signals, where source audio is 2ch PCM
- Supports up to 192kHz sample rates at 24bit depth
- Features optical audio breakout of multi-channel and 2ch audio formats
- Supports pass through of 5.1 surround sound to Optical or 2 channel to analogue and optical outputs
*Please note: the output of the ARC11 is a fixed line, and cannot be controlled via CEC volume commands from the display
Specifications:
- Audio Input Connectors: 1 x HDMI Type A, 19-pin, female
- Audio Output Connectors: 2 x RCA analogue left/right, 1 x Toslink optical output
- Dimensions (W x H x D): 70mm x 25mm x 73mm
- Operating Temperature: 32°F to 104°F (-5°C to +55°C)
- Storage Temperature: -4°F to 140°F (-25°C to +70°C)
- Power Supply: 5V/1A DC USB
Box Contents:
1 x ARC11
1 x 5V/1A DC USB Power Supply
1 x Mounting Kit
1 x Quick Reference Guide
