The Blustram HEX18GARC-KIT extender set is an industry leading uncompressed, unconverted HDMI 2.0 4K 60Hz 4:4:4 HDCP 2.3/2.2 solution utilising the latest in HDBaseT™ technology.
It supports uncompressed distribution of the latest HDR resolutions including HDR10/10+ and Dolby Vision resulting in the ultimate in picture quality for your critical viewing areas.
The HEX18GARC-KIT supports bi-directional IR, RS-232 and PoC up to lengths of 100m over a single CAT6A cable. The KIT also provides enhanced features including KVM, eARC via HDMI, or ARC via HDMI or Optical (S/PDIF), and 1Gb Ethernet pass through.
Key Features:
- Advanced uncompressed, unconverted, HDMI over HDBaseT™ technology offering distribution of bit-for-bit 4K HDMI video and audio over a single CAT6A cable
- Supports HDMI2.0 18Gbps specification including 4K 60Hz 4:4:4 UHD video
- Supports uncompressed distribution of the latest HDR resolutions including HDR10/10+ and Dolby Vision
- Supports HDMI video distribution up to 100m*
- Features 1x HDMI loop-out on HEX18GARC-TX for integrating local displays or cascading to multiple devices
- Supports all industry standard video resolutions including VGA-WUXGA and 480i-4K
- HDMI re-clocking on the HDBaseT™ Receiver to help solve HDMI HDCP, compatibility, and handshaking issues
- Supports eARC (Enhanced Audio Return Channel) from display via HDMI, and standard ARC from HDMI and Optical (S/PDIF) digital inputs
- Supports audio return to HDMI (eARC compatible), optical digital, and analogue L/R audio outputs (analogue output supports 2ch PCM only)
- Supports all known HDMI audio formats including Dolby Atmos, Dolby TrueHD, Dolby Digital Plus, and DTS-HD Master Audio transmissions
- Features USB 2.0 for KVM with speeds of up to 350Mbps
- Bi-directional Ethernet (1Gb), IR, & RS-232 pass through
- Supplied with Blustream IR receiver and emitter
- Bi-directional PoC (Power over Cable) to power extenders from either transmitter or receiver end
- Support for HDCP 2.3, HDCP 2.2 and HDCP 1.4
*Transmission distance is subject to video format, cable type and installation environment. The HDBaseT3 specification is based on using CAT6A F/UTP infrastructure or better. The use of CAT5e is not supported and CAT6 is not recommended due to potential bandwidth and performance issues.
Specifications:
HEX18GARC-TX
- Video Input Connectors: 1 x HDMI Type A, female
- Video Output Connectors: 1 x HDBaseT™ RJ45 connector, 1x HDMI Type A, female
- Audio Output Connectors: 1 x Analogue audio L/R (3.5mm stereo Jack), 1x Optical (S/PDIF)
- Ethernet port: 1 x RJ45 connector
- RS-232 serial port: 1 x 3-pin Phoenix connector
- USB/KVM Port: 1 x USB Type-B, 4 x USB Type-A
- IR Input ports: 1 x 3.5mm stereo jack
- IR Output ports: 1 x 3.5mm mono jack
- CTRL: 8-PIN DIP switch
HEX18GARC-RX
- Video Input Connectors: 1 x HDBaseT™ RJ45 connector, 1x HDMI Type A, female
- Video Output Connectors: 1 x HDMI Type A, female (reserved for future use)
- Audio Input Connectors: 1 x Optical (S/PDIF)
- Ethernet port: 1 x RJ45 connector
- RS-232 serial port: 1 x 3-pin Phoenix connector
- USB/KVM Port: 1 x USB Type-B, 4 x USB Type-A
- IR Input ports: 1 x 3.5mm stereo jack
- IR Output ports: 1 x 3.5mm mono jack
- CTRL: 8-PIN DIP switch
- Casing Dimensions (W x D x H ): 220mm x 100mm x 25mm (TX/RX)
- Operating Temperature: 32°F to 104°F (0°C to 40°C)
- Storage Temperature: -4°F to 140°F (-20°C to 60°C)
- Mounting kits included
- Power Supply: 1 x 24V/1.25A DC
Box Contents:
1 x HEX18GARC-TX Transmitter
1 x HEX18GARC-RX Receiver
1 x 24V/1.25A DC power supply
1 x USB-A to USB-B cable
1 x IRE1 receiver
1 x IRR emitter
4 x Mounting brackets
1 x Quick Reference Guide
